Holosun IRIS-GR4 - Green / IR Laser, White Light & VSCEL IR Illuminator

The Holosun IRIS-GR4 is a compact, advanced quad-function aiming and illumination system engineered to meet the demands of modern professionals and enthusiasts alike. Precision-machined from 7075-T6 aluminum, the redesigned housing is 43% lighter, 29% lower, and 28% narrower than the legacy LS420, offering superior ergonomics without compromising structural integrity—ideal for integration on PDWs, SBRs, and standard rifle platforms.

Quad-Function Lasers, IR Illuminator & White Light

At its core, the IRIS-GR4 combines a co-aligned visible green laser, infrared (IR) aiming laser, 60mW VCSEL-based IR illuminator, and a high-output white light delivering 1,000 lumens and 25,000 candela. This integration allows operators to transition seamlessly between daylight aiming, night vision engagements, and high-intensity white light use. The co-alignment of the lasers simplifies zeroing—users can calibrate both IR and VIS lasers simultaneously using the visible laser in daylight conditions, ensuring consistent point-of-aim across environments.

Adjustable VSCEL IR Illuminator & Ambidextrous Controls

A key feature of the IRIS-GR4 is its top-mounted IR beam divergence slider, which enables on-the-fly adjustment of the IR illuminator's beam pattern from wide flood to tight spot—optimized for performance across a range of shooting needs. Dual independent fire buttons offer tactile, ambidextrous control of laser and light functions, while the updated rear-positioned power and mode selector provides streamlined controls.

Remote Activation & Dual Power Options for Field Reliability

The included three-button remote switch connects via a Crane plug and offers a visible laser override function for rapid activation. For versatile power options, the IRIS-GR4 supports a rechargeable 18650 battery and dual CR123A batteries (included), providing dependable power in any operational setting.

FITMENT:

• Direct Mount: Picatinny

FEATURES:

• Quad-Function Laser and Illumination System
  Integrated green aiming laser, IR aiming laser, IR VCSEL illuminator, and high-output white light provide maximum versatility across day and night environments.

• High Visibility Green Laser
  520nm Class 3R green laser provides a crisp and highly visible aiming point for daylight use and simplified zeroing.

• Infrared Aiming Laser
  800–880nm Class 1 IR laser delivers precise aiming capability when operating with night vision devices.

• High Output IR VCSEL Illuminator
  60mW IR VCSEL illuminator enhances target identification and environmental awareness in low-light and no-light conditions.

• Adjustable IR Beam Divergence
  Top-mounted slider allows rapid adjustment from wide flood to tight spot for optimal illumination at varying distances.

• Integrated 1,000 Lumen White Light
  High-output white light produces 1,000 lumens and 25,000 candela for powerful visible illumination when needed.

• Co-Aligned Laser Zeroing System
  Visible and IR lasers are co-aligned, allowing both systems to be zeroed simultaneously using the visible laser during daylight.

• Advanced Control Interface
  Independent fire buttons and rear power selector provide intuitive control over laser and illumination functions.

• Remote Switch with VIS Override
  Included three-button Crane plug pressure pad allows remote activation with dedicated visible laser override capability.

• 7075-T6 Aluminum Rugged Housing
  Hard anodized aluminum construction provides excellent durability while maintaining a compact, lightweight footprint.

• Flexible Power Options
  Compatible with the included USB-C rechargeable 18650 battery or dual CR123A batteries for adaptable field power.

• IPX8 Waterproof Construction
  Fully sealed housing protects internal electronics from water exposure and harsh environmental conditions.

SPECIFICATIONS:

• Battery Type: 1x 18650 / 2x CR123A
• Housing Material: 7075 T6 Aluminum
• Adjustments per Click: 0.5 MOA
• W&E Travel Range: ±50 MOA
• IP Rating: IPX8
• Dimensions: 4.2" x 2.3" x 1.4"
• Weight: 8.5 oz
• Vibration: 1000G
• Storage Temperature: -40℃~70℃
• Operating Temperature: -30℃~51℃
• White Light Output: 1,000 Lumens
• White Light Candela: 25,000 Candela
• Green Laser Output Power: <5mW
• Green Laser Class: 3R
• Green Laser Wavelength: 520nm
• IR Laser Output Power: <0.7mW
• IR Laser Class: 1
• IR Laser Wavelength: 800-880nm
• IR VCSEL Illuminator Power: 60mW
• IR VCSEL Illuminator Wavelength: 800-880nm
